This machine is used for right-angle folding test of rubber products, shoe soles, PU and other materials. The test piece is continuously stretched and stretched by this machine, and after a certain number of times, the attenuation, damage and rupture degree are checked.

Meet the standards: HG/T 2411, ASTM D1052, ISO 5423, 4643, BS 513, SAFRA TM60

Product Parameters:

1. Angle: 90°±1°

2. Speed: ISO, SATRA: 60 times ±5/min; ASTM: 100 times ±5/min

3. Number of test pieces: 6 groups

4. Test piece: (L) 6″ x (W) 1″ x (D) sole 0.25″ rubber 0.5″

5. Counter: LCD 8-digit liquid crystal display

6. Machine size: 65×50×60cm

7. Weight: about 50kg

8. Power supply: AC～220V 50HZ
