Product Parameters |
capacity |
Min.Height |
Max.Height |
Platform Size |
Basement Size |
Lifting Time |
Net Weight |
Standard PowerPak |
Model |
(Kg) |
(mm) |
(mm) |
(mm) |
(mm) |
(s) |
(Kg) |
3phases 380V 50Hz AC2.2KW |
KT-MJ-A6001 |
6000 |
390 |
1150 |
1600x1000 |
1560x1000 |
25-35 |
540 |
|
KT-MJ-A6002 |
6000 |
390 |
1150 |
1800x1000 |
1560x1000 |
25-35 |
555 |
|
KT-MJ-A6003 |
6000 |
390 |
1150 |
1600x1400 |
1560x1000 |
25-35 |
586 |
|
KT-MJ-A6004 |
6000 |
390 |
1150 |
1800x1400 |
1560x1000 |
25-35 |
605 |
|
KT-MJ-A6005 |
6000 |
390 |
1150 |
1600x1500 |
1560x1500 |
25-35 |
670 |
|
KT-MJ-A6006 |
6000 |
390 |
1150 |
1800x1500 |
1560x1500 |
25-35 |
690 |
|
KT-MJ-A6007 |
6000 |
390 |
1150 |
1600x2000 |
1560x1500 |
25-35 |
728 |
|
KT-MJ-A6008 |
6000 |
390 |
1150 |
1800x2000 |
1560x1500 |
25-35 |
752 |
|
KT-MJ-A6009 |
6000 |
400 |
1600 |
2000x1000 |
1955x1000 |
30-40 |
675 |
|
KT-MJ-A6010 |
6000 |
400 |
1600 |
2200x1000 |
1955x1000 |
30-40 |
690 |
|
KT-MJ-A6011 |
6000 |
400 |
1600 |
2000x1400 |
1955x1000 |
30-40 |
728 |
|
KT-MJ-A6012 |
6000 |
400 |
1600 |
2200x1400 |
1955x1000 |
30-40 |
748 |
|
KT-MJ-A6013 |
6000 |
400 |
1600 |
2000x1500 |
1955x1500 |
30-40 |
835 |
|
KT-MJ-A6014 |
6000 |
400 |
1600 |
2200x1500 |
1955x1500 |
30-40 |
858 |
|
KT-MJ-A6015 |
6000 |
400 |
1600 |
2000x2000 |
1955x1500 |
30-40 |
908 |
|
KT-MJ-A6016 |
6000 |
400 |
1600 |
2200x2000 |
1955x1500 |
30-40 |
934 |
Features:
1.Heavy duty design.
2.Meet EN1570 norm and ANSI/ASME safety standard.
3.High quality power unit made in Europe.
4.Self lubricating bushings on pivot points.
5.Removable lifting eyes.
6.Upper platform lifted with aluminum safety bar preventing descenton contact with obstructions.
7.Internal power pack equipped with relief valve against overloadingand compensated flow valve for controlled lowering speed.
8.Heavy duty cylinders with drainage system and check valve to stopthe lift table lowering suddenly in case of hose burst.
9.Safety clearance between scissors to prevent trapping during operation.
