This machine is suitable for testing the normal temperature folding resistance of finished shoes and soles (sheets). Crack (mouth) and opening length of the sole and drawing strip, and observe the change of the upper.

This machine features:

The transmission adopts mechanical eccentric bearing, which is easy to maintain and has low noise;

The clamps are specially designed:

Upper clamp: Linear linear guide rail is adopted, which can be adapted to the clamping of special large-size and small-size shoes;

Lower clamp: By changing different positioning holes, it can adapt to the clamping requirements of different high and low toe caps. The locking device adopts an external rotation method, which is convenient to use.

Meet the standard: GB/T 3903.1

Product parameters:

1. Number of test pieces: 2

2. Bending angle: 0～55°(adjustable)

3. Test speed: 230±10 times/min, adjustable

4. Test blower device: 1 cast pipe/station

5. Counter: LCD 8-digit liquid crystal display

6. Machine size: 53×69×140cm

7. Weight: about 150kg

8. Power supply: AC～220V50HZ
