FEATURES ：

Mix double color injection machine is newly designed forproducingdouble color product such as tooth brush,comb,shoe upper etc.This machine adopt double servomotor system, two injection can work separately andsame time. Special controller is equipped on this machineto provide different injection function as per differentproduct.

Specifications：

1. Model:KT-140HS-A-B

2. Screw diameter : 42mm-A  32mm-B

3. Theoretical shot volume: 227cm3-A  104cm3-B

4. Injection weight(ps) :252g-A  95g-B

5. Injection rate : 115g/s-A  83g/s-B

6. Injection pressure : 171MPa-A  150MPa-B

7. Screw speed : 0~210rpm

8. Clamping force : 1400kN

9. Moving Mould-plate stroke : 380mm

10. Space between die bar(WxH) ：420x420mm

11. Max.Mould height :450mm

12. Min.Mould height :160mm

13. Ejector stroke :120mm

14.  Ejector force :50kN

15. Max.Pump pressure :16MPa

16. Pump motor power :18.2+12kW

17. Heating power :17kW

18. Machine dimension(LxWxH) :4.62x1.83x1.90m

19. Oiltank cubage :270L

20. Machine weight :4.5t
