Features:
1.Able to save information of multiple machining holes, and reedit and save original machining holes.
2.Able to display machining track lines and simulate machining order in the area of holes under unmachining conditions.
3.Able to forcedly exit the machining of the current hole and switch to the next hole to machine in the process of multiple-hole machining.
4.In the process of machining, a first click automatically elevates the electrode changing system,and a second click recovers the machining state.
5.The CNC punch machines multiple holes,and the system has two ways to add hole machining information.
Adding hole information one by one,which is suitable for adding holes that are scattered and distributed irregularly.
Using formulas to add hole information, which is suitable for hole information that is distributed in certain rules.
6.Able to change, add and delete as well as adjust the machining order of the holes at any time.
7.Able to machine hole diameters of Φ0.3-Φ3.0 mm, and the maximum depth-diameter ratio can reach over 300:1.
8.The machining speed can reach 5 - 40 mm per minute with a servo stroke of 300, and super-long electrode tubes can be used to save15% of electrode tubes.
9.Able to machine stainless steel, quenched steel,hard alloy, copper, aluminum and other conductive materials.
10.Able to penetrate directly from inclined surfaces and curved surfaces.
11.Linear ball guide rail is adopted for electric servo movement, ensuring the machining precision and speed of products.
12.The main spindle adopts double-speed control mode, making the returning speed twice as quick as the machining speed and closely tracking during machining, so as to realize high-efficiency and stable machining of thin electrodes.
13.An observation window for the pressure of water pump is designed on the machine bed to make the observation and adjustment of the pressure of water pump more convenient and simpler.
Product Parameters:
1.Diameter of electrode(mm):Φ0.3-Φ3.0
2.stroke of Spindle(mm):280
3.stroke of servo(mm):300
4.Maximum speed of spindle(mm/min):120
5.of rotation(rpm):40-60
6.Worktable size(mm):200x300
7.X-Y table travel(mm)350x480
8.X/Y/Z axis rapid traverse rate(m/min):30/30/30
9.maximum distance form guider to worktable(mm):330
10.Spindle drive motor(KW):1.5KW
11.X/Y/Z shaft drive motor(KW):0.75kw
12.Cutting water motor:760W
13.positioning accuracy(mm/全行程):±0.01
14.Repeatability accuracy(mm/全行程:±0.005
15.table carrying weight:350kg
16.Height of worktable(mm):920
17.Maximum working current:30A
18.Maximum input consumption:3KW
19.Power input:3N-380V/50HZ
20.filtering of work liquid:25l
21.Work liquid filtering:浅隙式
22.Maximum working fluid pressure:6Mpa
23.Machine dimensions (L*W*H)mm:1200x1500x2000
24.Machine weight:650kg
