Product Parameters：

1. MODEL ：KT-863C

2. Dimension(LxWxH) :1140x720x1300mm

3. Power : 1kw

4. Voltage : AC220V

5. Air pressure : 4-5.5MPa

6. Weight ：220kg

Application : Widely used in flat-bottom,arc insole/tongue heattransfer,bronzing machine,leatherimprint processing,etc.

Features:

1. This machine adopts all imported electrical and pneumatic parts,morestable and durable;

2. The machine is also fixed with the PLC, HMl, and PiD temperature modulefor accurate temperature control, so the temperature difference isonlyaround±1 degree centigrade;

3. The machine is fixed with imported color standard sensors, canaccuratelydo 7 colors discrimination and high precision positioning.entertainmentdifference within+0.02mm.

4. The machine with unique hot stamping function,when there isnomaterial,the hot stamping die will stop hotstamping by itself.

5. The machine is with Japanese stepping motor, so easily reach stableandreliable label rolling and label feeding job.

6. The machine adopts the principle that the motor runs in thereversedirection in unwinding,so that the tape is always tightened toreduce the entertainmentdifference during standard running.

7. Power frequency can be adjusted without noise.

8. This machine is withthe op tion of:autolab elhea ttrans fer , hot stamping.

and embossing, more flexible in production.
