FEATURES ：

Adopt special design for PET material,long L/D to increase theefficiency of charging and shot weight.

Increased ejector force and stroke to improve the ejectingspeed.

servo energy saving system could be chosen for machine,electricity consumption will be reduced 30% to 50%.

we can provide full set equipment for PET bottle such asinjection machine,blow moulding machine,mould and otheraccessories.

Specifications：

1. Model:KT-230PETS

2. Screw diameter : 55mm

3. Shot volume(theoretical) : 593cm3

4. Injection weight(ps) :640g

5. Injection rate : 200g/s

6. Injection pressure : 138MPa

7. Screw speed : 0~155rpm

8. Clamping force :2300kN

9. Moving Mould-plate stroke : 475mm

10. Space between tie bars(WxH) ：530x530mm

11. Max.Mould height :580mm

12. Min.Mould height :200mm

13. Hydraulic Ejector stroke :140mm

14. Hydraulic Ejector force :70kN

15. Max.Pump pressure :16MPa

16. Pump motor power :28.3kW

17. Heating power :19.6kW

18. Machine dimension(LxWxH) :5.75x1.50x2.14m

19. Oiltank cubage :300L

20. Machine weight :7t
