Single Group Vulcanizing Machine 63tons KT-DJ63T-1

Power supply specification: 380V/50HZ
Overall machine size: 1600*1200*1600mm
Machine weight: 1300Kg

Product Details

Product Tags

Product Parameters:

1.Model: KT-DJ63T-1

2. Hot plate specifications: 400*400mm

3. Temperature range: normal temperature -350℃

4.Hot plate spacing: 200mm

5. Heating method: imported electric heating tube

6. Mold opening method: automatic mold release

7. System pressure: 18MPa

8. Main column diameter: Φ210mm

9. Clamping stroke: 220mm

10. Working level: upper and lower levels

11. Motor power: 3.75KW

12. Maximum pressure: 63 tons

13.Total power: 13KW

14. Machine structure: four-column/single-head model

15. Power supply specification: 380V/50HZ

16. Overall machine size: 1600*1200*1600mm

17. Machine weight: 1300Kg
