USE

This machine is mainly used for riveting for shoe eyelets in single-row or multi-row of all kinds of fabric belts and leather belts.

Feature:

1.Adopt PLC and touch screen control, display fault detection automatically.It's easy to maintain and user-friendly to operate.

2.Automatic punching,feeding and riveting eyelets can be completed at one time.

3.Multiple riveting modes are available:single row,multiple rows,custom mode and segment mode.

a.Single row and multiple-row mode:fill in the X and Y axis data to rivet eyelet in tape or leather belt;

b.Custom mode:after the distance required for each eyelet is programmed,the eyelet can be riveted;

c. Segment mode:for the entire fabric belt or leather belt,after programming required data and riveting, it can clip by segments.

Product Parameters：

1.Model:KT-98A

2.Voltage:220V 50Hz

3.Power:0.95kW

4.Working speed:120times/min

5.Nailing size:NO.:150-600#

Size:8≥Inside diameter≥3.5mm

:Height≥2.2mm

6.Dimension:1092x770x1530mm

7.Gross weight/Net weight:280kg/240kg
