EFFICIENT LOW SPEED MUTE CRUSHER




Product Details

Product Tags

Product Parameters

Model

KT-2000

KT-3000

KT-5000

KT-8000

Power

2.2KW

3.7KW

3.7KW

7.5KW

The rotor diameter(mm)

185

185

185

300

The width of the rotor(mm)

335

395

395

600

Therotorspeed(r/min)

150

150

150

150

Number of moving knives(P)

24

30

45

33

Number of fixed knife(P)

8

10

15

11

Crushing capacity

50-100(kg/h)

70-150(kg/h)

100-200(kg/h)

500-600(kg/h)

Input size(length width)

280x235mm

290x280mm

430x280mm

400x400mm

Bodysize(length width height)

800x435x1230mm

800x435x1230mm

900x500x1240mm

1450x900x1600mm

Machine weight

200kg

225kg

255kg

810kg









Features:

1. All the rotor box cushing warehouses of HC series have been redesigned to increase the crushing yield of

hollow materials such as plastic bottles and other blow molding products and improve the crushing effect.

2. The re-design of the crushing bin has also increased its size, and even larger gate materials can be easilyinvested, so the scope of application of the HC seriesMore broadly. The rotor is supported on two bearings, while itsshaft diameter is desianed accordina to the maximum rotor width, so that it can be chopped into blocksPossible. inaddition, the stepped rotor blade design allows only one tool to be cutting at any one time, thus increasing the cutingtoraue, Based onFor these reasons, the HC series machines are suitable for cutting dense materials and thick.walled gates
